Google Tensor G5 Specs

Google Tensor G5
8 Cores
8 Threads
3.78GHz Clock
Socket
Unknown
iGPU
IMG DXT-48-1536 1100MHz
1.69 TFLOPS FP32
GB6S 2,475
61%
GB6M 6,880
26%
CB23S N/A
0%
CB23M N/A
0%
Manufacturer
Google
Architecture
ARMv9.2-A
Family
-
Instruction Set (ISA)
AArch64
Codename
-
-
-
P-Core
Cortex-X4
M-Core
Cortex-A725
E-Core
Cortex-A520
Market Segment
Mobile
Release Date
8/20/2025
Foundry
TSMC
-
-
-
Node
N3E
-
-
-
Die Size
Unknown
-
-
-
Transistor Count
Unknown
-
-
-
Unknown
8 Cores
1 P-Cores
5 M-Cores
2 E-Cores
8 Threads
1 P-Threads
5 M-Cores
2 E-Threads
P-Core
3.78GHz
-
-
M-Core
3.05GHz
-
E-Core
2.25GHz
-
Overclocking
Locked
-
-
-
Integrated Chipset
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
L0 Instruction
-
-
L0 Data
-
-
L1 Instruction
64KB/P-Core
4-way set associative
64KB/M-Core
4-way set associative
16KB/E-Core
4-way set associative
L1 Data
64KB/P-Core
4-way set associative
64KB/M-Core
4-way set associative
16KB/E-Core
4-way set associative
L2
1024KB/P-Core
8-way set associative
-
-
256KB/M-Core
8-way set associative
-
-
128KB/E-Core
8-way set associative
-
-
L3
-
4MB Shared
-
16-way set associative
-
-
-
-
-
-
-
-
8MB SLC Cache
Channels
4
Max Memory
16GB
ECC
Not Supported
Bus Width/Channel
16Bit
Bus Width
64Bit
Clock
4267MHz
Transfer Rate
8533MT/s
Bandwidth/Channel
17.1GB/s
Bandwidth
68.3GB/s
TDP
10W
-
-
-
-
-
-
Included Cooler
Not Included
No PCIe
IMG DXT-48-1536 1100MHz
768 Shaders
1100MHz
1.69 TFLOPS FP32
Edge TPU Gen 4
-
16 Cores
16.4 TOPS
-
-
No Cellular
