Intel Xeon 654 Specs
Intel Xeon 654
$1,199
|
18 Cores
36 Threads
3.1GHz Clock
|
|
Socket
LGA 4710
|
|
iGPU
No GPU
- -
|
|
GB6S N/A
0%
|
|
GB6M N/A
0%
|
|
CB23S N/A
0%
|
|
CB23M N/A
0%
|
|
Manufacturer
Intel
|
|
Architecture
Granite Rapids
|
|
Family
Xeon 6
|
|
Instruction Set (ISA)
x86-64
|
|
Codename
-
24
Granite Rapids-HCC
-
Redwood Cove
M-Core
18
-
-
|
|
Market Segment
Workstation
|
|
Release Date
2/2/2026
|
|
Foundry
Intel
Intel (IO Die)
-
-
|
|
Node
Intel 3
Intel 7 (IO Die)
-
-
|
|
Die Size
598 mm²
2x 241 mm² (IO Die)
-
-
|
|
Transistor Count
Unknown
-
-
-
|
|
18 Cores
-
-
-
|
|
36 Threads
-
-
-
|
|
-
3.1GHz
4.8GHz Boost
-
|
|
-
-
-
|
|
-
-
-
|
|
Overclocking
Locked
-
-
-
|
|
Integrated Chipset
-
|
|
-
-
|
|
-
-
|
|
-
-
|
|
-
-
|
|
-
-
|
|
-
-
|
|
-
-
|
|
L0 Instruction
-
-
|
|
L0 Data
-
-
|
|
L1 Instruction
64KB/Core
8-way set associative
-
-
-
-
|
|
L1 Data
48KB/Core
12-way set associative
-
-
-
-
|
|
L2
2048KB/Core
16-way set associative
-
-
-
-
-
-
-
-
-
-
|
|
L3
-
72MB Shared
-
12-way set associative
-
-
-
-
-
|
|
-
-
-
-
|
|
Channels
8
|
|
Max Memory
4096GB
|
|
ECC
Supported
|
|
Bus Width/Channel
64Bit
Bus Width
512Bit
|
|
Clock
1600MHz
Transfer Rate
6400MT/s
|
|
Bandwidth/Channel
51.2GB/s
Bandwidth
409.6GB/s
|
|
TDP
200W
-
-
240W Peak
|
|
Temp
96°C Max
72°C TCase
|
|
Included Cooler
Not Included
|
|
PCIe 5.0 x128 Lanes
|
|
No GPU
-
-
- -
|
|
No NPU
-
|
|
-
-
|
|
-
|
|
-
-
|
|
No Cellular
|
