NVIDIA RTX PRO 5000 Blackwell Laptop Full Specs

Summary

10,496 Shaders 2.37GHz

24GB GDDR7896GB/s

Peak·FP32·FP16 49.8 TFLOPS

Form Factor Soldered

TDP 175W

Highlights

Peak OPS

Peak OPS FP32 FP16 Tensor NVFP4 NVFP4 Tensor Sparse Tensor FP4 FP4 Tensor Sparse Tensor FP8-16 FP8-16 Tensor Sparse Tensor FP8-32 FP8-32 Tensor Sparse Tensor FP16-16 FP16-16 Tensor Sparse Tensor FP16-32 FP16-32 Tensor Sparse FP64 BF16 Tensor BF16 BF16 Tensor Sparse Tensor TF32 Tensor INT8 INT32 Memory Bandwidth

RTX PRO 5000 Blackwell Laptop1.82 PFLOPSNVFP4 Tensor Sparse

x1

Top Score3.35 PFLOPS FP4 Tensor Sparse

x1.84

Desktop1xGeForce RTX 5090

Theoretical Performance

Clock Speed2372MHz UC·Base·Boost·OC

Peak OPS 1.82 PFLOPSNVFP4 Tensor Sparse

Tensor FP4 912 TFLOPS FP4 Tensor Sparse 1.82 PFLOPS NVFP4 Tensor 912 TFLOPS NVFP4 Tensor Sparse 1.82 PFLOPS

Tensor FP8-16 456 TFLOPS FP8-16 Tensor Sparse 912 TFLOPS Tensor FP8-32 456 TFLOPS FP8-32 Tensor Sparse 912 TFLOPS

FP16 49.8 TFLOPS Tensor FP16-16 228 TFLOPS FP16-16 Tensor Sparse 456 TFLOPS Tensor FP16-32 228 TFLOPS FP16-32 Tensor Sparse 456 TFLOPS

BF16 49.8 TFLOPS Tensor BF16 228 TFLOPS BF16 Tensor Sparse 456 TFLOPS

Tensor TF32 114 TFLOPS

FP32 49.8 TFLOPS

FP64 778.1 GFLOPS

Tensor INT8 456 TOPS

INT32 49.8 TOPS

Ray 151 TOPS

Pixel Rate 265.7 GPixel/s

Texture Rate 778.1 GTexel/s

Core Config

Shaders 10,496 Shaders

TMUs 328 TMUs

ROPs 112 ROPs

Tensor Cores 328 T-Cores

RT Cores 82 RT-Cores

SMs 82 SMs

Clocks

Base Clock 1.4GHz

Boost Clock 2.37GHz

Tensor Clock 2.71GHz

Cache

L1 64KB/SM Tex

L2 Cache 64MB shared

Memory

24GB GDDR7

Memory Bus 256-bit

Memory Speed 28GT/s

Memory Bandwidth 896GB/s

ECC Yes

Power & Thermals

TDP 175W

Video Output

Max Resolution 7680x4320

Refresh Rate Calculator 7680x4320 Resolution8K UHD Refresh Rate 165Hz

Multi-Monitor 4

Adaptive Sync G-Sync FreeSync

DSC Supported

HDCP HDCP 2.3

API Support

Shader Model 6.8

DirectX DirectX 12 Direct3D 12_3

OpenGL 4.6 OpenCL 3 Vulkan 1.3

CUDA 12.8 PureVideo HD VP13 VDPAU Feature Set M

Encoder

Encoder 3x NVENC 9

Codec AVC (H.264) HEVC (H.265) AV1

Decoder

Decoder 3x NVDEC 6

Codec MPEG-1 MPEG-2 MPEG-4 VC-1 VP8 VP9 AVC (H.264) HEVC (H.265) AV1

Card

Form Factor Soldered

PCIe PCIe 5.0 x16

Chip

Manufacturer NVIDIA

Chip Designer NVIDIA

Architecture Blackwell

Family RTX PRO Blackwell

Branding

Codename NV193

Market Segment Laptop

Release Date Mar 18, 2025

Fabrication

Foundry TSMC

Fabrication Node 4N

Die Size 378mm²

Transistor Count 45.6B

Transistor Density 120.6 MTr/mm²
